CAMF 42U 800X1000
FLOOR STANDING NETWORK ENCLOSURE 42U 800×1000
Specification
Model No
CAMF42U1000D
Capacity
42U
Width
800 mm
Depth
1000 mm
Height
1970 mm
Features
- Rack Standard: Conforms to DIN 41494 or ISO equivalent standard
- Construction: Welded
- Front Door: Lockable Toughened Glass Door, Lock & Keys
- Basic Frame: CRCA Steel
- Equipment Mounting: DIN Standard Slots
- Angle: 19″ mounting angles made of formed steel
- Finish: 7-Layer Powder Coated
- Top & Bottom Cover: Welded to frame, vented with field cable-entry exit cut-outs
- Colour: Frame RAL 7035, Door RAL 7037
- Static Load:Upto 800 kgs
Technical Data are typical values and subject to change without notice.
